60
1MRS 751108-MUM
3URWHFWLRQ5HOD\
Technical Reference Manual, General
5(;
**) Breaker failure is generated by all the protection functions
***) Also DPI values 0 (Middle) and 3 (Faulty) are transferred
&RPPDQGV
Explanations to the Table 10.5.-2:
f2 Underfrequency or overfrequency, St2, START2 P 172 94 1 1 1,9 Freq1St2
f2 Underfrequency or overfrequency, St2, TRIP2 P 172 91 0 1 1 Freq1St2
PQ 3Inf Current harmonic limit P 204 20 0 1 1 PQCU3H
PQ 3Unf Voltage waveform distortion measurement P 205 20 0 1 1 PQVO3H
ALARM1 ALARM1 status P 253 88 1 1 1,9 MMIALAR1
ALARM2 ALARM2 status P 253 89 1 1 1,9 MMIALAR2
ALARM3 ALARM3 status P 253 90 1 1 1,9 MMIALAR3
ALARM4 ALARM4 status P 253 91 1 1 1,9 MMIALAR4
ALARM5 ALARM5 status P 253 92 1 1 1,9 MMIALAR5
ALARM6 ALARM6 status P 253 93 1 1 1,9 MMIALAR6
ALARM7 ALARM7 status P 253 94 1 1 1,9 MMIALAR7
ALARM8 ALARM8 status P 253 95 1 1 1,9 MMIALAR8
TIME1 Accumulated time 1 alarm P 238 12 1 1 1,9 CMTIME1
TIME1 Accumulated time 1 measurement P 238 11 1 1 1,9 CMTIME1
FUSEF Fuse failure P 253 83 1 1 1,9 FUSEFAIL
AC fail P 240 181 1 1 1, 9 system
IRF test P 239 11 0 1 1 system
IRF error P 239 12 1 1 1, 9 system
Local parameter setting done P 10 22 0 1 1 system
7DEOH &ODVVGDWDVLJQDOV&RQWLQXHG
)XQFWLRQEORFN
,(&QDPH
6W )W\S
,QIR
1XP
*, 7\S &27
)XQFWLRQEORFN
$%%QDPH
6W
Status
A According to the IEC 60870-5-103 standard
B According to “Digitale Stationsleittechnik - Ergänze Empfehlungen zur
Anwendung in Verteilnetzstationen”
P Private definition
)W\S
Function type
If stated as *), the signal type Ftyp corresponds with the unit function
type. Unit function type may be adjusted via the Function type
parameter.
,QIR1XP
Information element number
&27FPG
Cause of transmission values in command direction
20 General command
&27UHVS
Cause of transmission values in response direction
20 Positive acknowledgement
21 Negative acknowledgement
!
