ABB Industrial IT enabled REX 521 - Page 61

1MRS 751108-MUM
3URWHFWLRQ5HOD\
Technical Reference Manual, General
5(;
61
&ODVVPHDVXUDQGVHWV
Explanations to the Table 10.5.-3:
The measurand sets 2, 3, 5, 6, 7, 8 and 9 are not relevant for the Basic and Medium
versions of the protection relay. The default measurand set is 11.
*) According to the device function type
7DEOH &RPPDQGV
D
a.When controlling the output relays by using the IEC_103 protocol, the interlocking of
the standard configuration is bypassed. It is not allowed to use the same output relay as
a tripping contact and as an IEC_103 controlling object simultaneously
&RPPDQGV 6W )W\S
,QIR
1XP
7\S
&27
FPG
&27
UHVS
I<->0 CB1: control CB1 B 240 160 20 20 20,21
Output relay 1 control (HSPO1) P 251 27 20 20 20,21
Output relay 2 control (PO1) P 251 28 20 20 20,21
Output relay 3 control (PO2) P 251 29 20 20 20,21
Output relay 4 control (PO3) P 251 30 20 20 20,21
Output relay 5 control (SO1) P 251 31 20 20 20,21
Output relay 6 control (SO2) P 251 32 20 20 20,21
6HW1R
Class 2 measurand set No (1...11)
6W
Status
A According to the IEC 60870-5-103 standard
P Private definition
0HDV
Measurand class I or II
)XQF7\SH
,QIR1XP
Class 2 Frame identification
If stated as *), the signal type Ftyp corresponds with the unit function
type. Unit function type may be adjusted via the Function type
parameter.
1XPGDWD
The number of the data values in the class 2 message data part
7\S
Meas type 3 or 9 (when the definition is private, meas type 9 is used)
'DWD
Measurement data in class 2 message data part:
Not available: -
!
!
7DEOH 5HFRPPHQGHG&ODVVPHDVXUDQGVHWV
6HW1R 6W 0HDV
)XQF
7\SH
,QIR
1XP
1XP
GDWD
7\S 'DWD
1 Meas I: 144 A I *) 144 1 3
IL2
2 Meas I: 145 A I *) 145 2 3
IL2, U12
3 Meas I: 146 A I *) 146 4 3
IL1, U12, P, Q
4 Meas I: 147 A I *) 147 2 3
Io, Uo
5 Meas II: 148 A II *) 148 9 9
IL1, IL2, IL3, U1, U2, U3, P, Q, f
6 Meas II: ABB1 P II 134 137 16 9
IL1, IL2, IL3, Io, -, -, -, U12, U23, U31, P, Q, f, -, -, pf
7 Meas II: ABB2 P II 134 137 16 9
IL1, IL2, IL3, Io, U1, U2, U3, -, -, -, P, Q, f, -, -, pf
8 Meas II: ABB3 P II 135 137 12 9
IL1, IL2, IL3, U1, U2, U3, Io, Uo, P, Q, pf, f
9 Meas II: ABB4 P II 135 138 12 9
IL1, IL2, IL3, U12, U23, U31, Io, Uo, P, Q, pf, f
10 Meas II: Basic P II 135 139 4 9
IL1, IL2, IL3, Io
11 Meas II: Medium P II 135 140 5 9
IL1, IL2, IL3, Io, Uo
