4 Repair
4.2.3. Mounting instructions for seals
1113HAC026660-001 Revision: C
© Copyright 2006-2008 ABB. All rights reserved.
Flange seals and static seals
The procedure below details how to fit flange seals and static seals.
O-rings
The procedure below details how to fit o-rings.
Action
1. Check the flange surfaces. They must be even and free from pores.
It is easy to check flatness using a gauge on the fastened joint (without sealing
compound).
If the flange surfaces are defective, the parts may not be used because leakage could
occur.
2. Clean the surfaces properly and in accordance with ABB recommendations.
3. Distribute the sealing compound evenly over the surface, preferably with a brush.
4. Tighten the screws evenly when fastening the flange joint.
Action Note
1. Ensure that the correct o-ring size is used.
2. Check the o-ring for surface defects, burrs, shape accuracy, etc. Defective o-rings may
not be used.
3. Check the o-ring grooves.
The grooves must be geometrically correct and free from pores
and contamination.
Defective o-rings may
not be used.
4. Lubricate the o-ring with grease.
5. Tighten the screws evenly when assembling.
Continued
To Next Page
