ABB IRB 1600 - 5/1,2 type A - Brake Testing

1 Safety
1.2.3.4. Brake testing
3HAC026660-001 Revision: C24
© Copyright 2006-2008 ABB. All rights reserved.
1.2.3.4. Brake testing
When to test
During operation the holding brake of each axis motor wear normally. A test may be
performed to determine whether the brake can still perform its function.
How to test
The function of the holding brake of each axis motor may be checked as detailed below:
1. Run each robot axis to a position where the combined weight of the robot arm and any
load is maximized (max. static load).
2. Switch the motor to the MOTORS OFF position with the Operating mode selector on the
controller.
3. Check that the axis maintains its position.
If the robot does not change position as the motors are switched off, then the brake
function is adequate.
