AUTOMATIC CONTROL UNIT, OMD800
AUTOMATIC CONTROL UNIT, OMD800
Register Address R/W Values
REG_DI4_CONTACT_TYPE 647 R/W 0 = NO
1 = NC
REG_DI5_CONTACT_TYPE 648 R/W See REG_DI4_CONTACT_TYPE values
REG_DI6_CONTACT_TYPE 649 R/W See REG_DI4_CONTACT_TYPE values
REG_DI7_CONTACT_TYPE 650 R/W See REG_DI4_CONTACT_TYPE values
REG_DI8_CONTACT_TYPE 651 R/W See REG_DI4_CONTACT_TYPE values
REG_DI9_CONTACT_TYPE 652 R/W See REG_DI4_CONTACT_TYPE values
REG_DI10_CONTACT_TYPE 653 R/W See REG_DI4_CONTACT_TYPE values
REG_DI11_CONTACT_TYPE 654 R/W See REG_DI4_CONTACT_TYPE values
REG_DO6_FUNCTION 655 R/W 0 = No function
1 = Emergency/alarm
2 = Line I status
3 = Line II status
4 = Change-over switch alarm
5 = Manual mode
6 = Disconnect secondary loads
7 = Pre-transfer signal
8 = I Status
9 = O Status
10 = II Status
REG_DO7_FUNCTION 656 R/W See REG_DO6_FUNCTION values
REG_DO8_FUNCTION 657 R/W See REG_DO6_FUNCTION values
REG_DO9_FUNCTION 658 R/W See REG_DO6_FUNCTION values
REG_DO10_FUNCTION 659 R/W See REG_DO6_FUNCTION values
REG_DO12_FUNCTION 660 R/W See REG_DO6_FUNCTION values
REG_DO6_CONTACT_TYPE 661 R/W 0 = NO
1 = NC
REG_DO7_CONTACT_TYPE 662 R/W See REG_DO6_CONTACT_TYPE values
REG_DO8_CONTACT_TYPE 663 R/W See REG_DO6_CONTACT_TYPE values
REG_DO9_CONTACT_TYPE 664 R/W See REG_DO6_CONTACT_TYPE values
REG_DO10_CONTACT_TYPE 665 R/W See REG_DO6_CONTACT_TYPE values
REG_DO12_CONTACT_TYPE 666 R/W See REG_DO6_CONTACT_TYPE values
REG_VOLT_THRESHOLD_LN1_MIN 881 R/W 5...30 %
REG_VOLT_THRESHOLD_LN1_MAX 882 R/W 5...30 %
REG_VOLT_THRESHOLD_LN2_MIN 883 R/W 5...30 %
REG_VOLT_THRESHOLD_LN2_MAX 884 R/W 5...30 %
REG_VOLT_HYSTERESIS_LN1_MIN 885 R/W 4...29 %
REG_VOLT_HYSTERESIS_LN1_MAX 886 R/W 4...29 %
REG_VOLT_HYSTERESIS_LN2_MIN 887 R/W 4...29 %
REG_VOLT_HYSTERESIS_LN2_MAX 888 R/W 4...29 %
REG_FREQ_THRESHOLD_LN1_MIN 891 R/W 1...10 %
REG_FREQ_THRESHOLD_LN1_MAX 892 R/W 1...10 %
REG_FREQ_THRESHOLD_LN2_MIN 893 R/W 1...10 %
REG_FREQ_THRESHOLD_LN2_MAX 894 R/W 1...10 %
REG_FREQ_HYSTERESIS_LN1_MIN 895 R/W 8...98 (0.8 ... 9.8 %)
REG_FREQ_HYSTERESIS_LN1_MAX 896 R/W 8...98 (0.8 ... 9.8 %)
REG_FREQ_HYSTERESIS_LN2_MIN 897 R/W 8...98 (0.8 ... 9.8 %)
REG_FREQ_HYSTERESIS_LN2_MAX 898 R/W 8...98 (0.8 ... 9.8 %)
