11 Technical data
Manufacturer
Address
ABB JOKAB SAFETY
Varlabergsvägen 11
SE-434 39 Kungsbacka
Sweden
Electrical data
Power supply (Vdd):
+24 VDC ± 20 %
Consumption (TX):
1.5 W max
Consumption (RX):
4 W max (without load)
Outputs
2 PNP
Short-circuit protection:
Output current:
Output voltage – ON:
Output voltage – OFF:
Capacitive load:
1.4 A max
0.5 A max / output
Vdd -1 V min
0.2 V max
2.2 µF at +24 VDC max
Response time:
See paragraph 12 – “Model overview”
Electrical protection:
Class III – use SELV/PELV
Connections:
Transmitter: M12 4-pole male connector
Receiver: M12 8-pole male connector
Cable length (for power supply):
50 m max
Optical data
Light emission (  ):
Infrared, LED (950 nm)
Resolution:
14 – 30 mm
Protected height:
150..1800 mm. See paragraph 12 – “Model overview”
Operating distance:
0.2…19 m for 30 mm
0.2…6 m for 14 mm
Ambient light rejection:
According to IEC 61496-2:2013
Mechanical and environmental data
Operating temperature:
0…+ 55 °C
Storage temperature:
- 25…+ 70 °C
Temperature class:
T6
Humidity:
15…95 % (no condensation)
Mechanical protection:
IP65 (EN 60529:2000)
Vibrations:
Width 0.35 mm, Frequency 10 … 55 Hz,
20 sweeps per axis, 1 octave/min
(EN 60068-2-6:2008)
Shock resistance:
16 ms (10 G) 10
3
shocks per axis
(EN 60068-2-29:2008)
Housing material:
Painted aluminium (yellow RAL 1003)
Front glass material:
PMMA
Cap material:
PC MAKROLON
Weight:
1.3 kg / meter for each single unit
