ABB Orion1 Base - Model Overview

2TLC172287M0201 Rev B 38 www.abb.com/jokabsafety
2015-09-17
12 Model overview
Type
Article number
Protected
height
(mm)
Number of
beams
Response
time
(ms)
Resolution
(mm)
Orion1-4-14-015-B
2TLA022300R0000
150
16
11
14
Orion1-4-14-030-B
2TLA022300R0100
300
32
15
14
Orion1-4-14-045-B
2TLA022300R0200
450
48
18
14
Orion1-4-14-060-B
2TLA022300R0300
600
64
22
14
Orion1-4-14-075-B
2TLA022300R0400
750
80
25
14
Orion1-4-14-090-B
2TLA022300R0500
900
96
29
14
Orion1-4-14-105-B
2TLA022300R0600
1050
112
33
14
Orion1-4-14-120-B
2TLA022300R0700
1200
128
36
14
Orion1-4-14-135-B
2TLA022300R0800
1350
144
40
14
Orion1-4-14-150-B
2TLA022300R0900
1500
160
43
14
Orion1-4-14-165-B
2TLA022300R1000
1650
176
47
14
Orion1-4-14-180-B
2TLA022300R1100
1800
192
50
14
Orion1-4-30-015-B
2TLA022302R0000
150
8
9
30
Orion1-4-30-030-B
2TLA022302R0100
300
16
11
30
Orion1-4-30-045-B
2TLA022302R0200
450
24
13
30
Orion1-4-30-060-B
2TLA022302R0300
600
32
14
30
Orion1-4-30-075-B
2TLA022302R0400
750
40
16
30
Orion1-4-30-090-B
2TLA022302R0500
900
48
18
30
Orion1-4-30-105-B
2TLA022302R0600
1050
56
19
30
Orion1-4-30-120-B
2TLA022302R0700
1200
64
21
30
Orion1-4-30-135-B
2TLA022302R0800
1350
72
23
30
Orion1-4-30-150-B
2TLA022302R0900
1500
80
25
30
Orion1-4-30-165-B
2TLA022302R1000
1650
88
26
30
Orion1-4-30-180-B
2TLA022302R1100
1800
96
28
30
