50 Parameters
114.76 AO1 actual (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Displays the value of AO1 in mA.
This parameter is read-only.
-
0.000 ... 22.000 mA Value of AO1. 1000 = 1 mA
114.77 AO1 source (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Selects a signal to be connected to analog output
AO1.
Zero
Zero 0
DC voltage 101.01 DC voltage 1
Line current 101.02 Line current 2
Power 101.12 Power 3
Frequency 101.08 Frequency 4
Temperature sensor
excitation
117.12 PT sensor current actual 5
Inverter temperature A 173.24 Inverter temperature A 6
Inverter temperature B 173.25 Inverter temperature B 7
Inverter temperature C 173.26 Inverter temperature C 8
114.80 AO1 source min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the real value of the signal (selected by
parameter 114.77 AO1 source) that corresponds
to the minimum AO1 output value (defined by
parameter 114.82 AO1 out at AO1 src min).
0.0
-32768.0 … 32767.0 Real signal value corresponding to minimum AO1
output value.
1 = 1
114.81 AO1 source max (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the real value of the signal (selected by
parameter 114.77 AO1 source) that corresponds
to the maximum AO1 output value (defined by
parameter 114.83
AO1 out at AO1 src max). See
parameter 114.80 AO1 source min.
100.0
-32768.0 … 32767.0 Real signal value corresponding to maximum
AO1 output value.
1 = 1
114.82 AO1 out at AO1 src min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the minimum output value for analog
output AO1. See also drawing at parameter
114.80 AO1 source min.
0.000 mA
0.000 … 22.000 mA Minimum AO1 output value. 1000 = 1 mA
114.83 AO1 out at AO1 src max (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the maximum output value for analog
output AO1. See also drawing at parameter
114.80 AO1 source min.
10.000 mA
0.000 … 22.000 mA 1000 = 1 mA
No. Name/Value/Range Description Default
FbEq (16b/32b)
