Parameters 49
114.59 AI3 HW switch position (Visible only when parameter 114.0 1 Option
module 1 type is FIO-11.)
Shows the position of the hardware
current/voltage selector on the I/O extension
module.
Note: The setting of the current/voltage selector
must match the unit selection made in parameter
114.60 AI3 unit selection.
-
VVolts 2
mA Milliamperes 10
114.60 AI3 unit selection (Visible only when parameter 114.0 1 Option
module 1 type is FIO-11.)
Selects the unit for readings and settings related
to analog input AI3.
Note: This setting must match the corresponding
hardware setting on the I/O extension module
(see the manual of the I/O extension module).
The hardware setting is shown by parameter
114.59 AI3 HW switch position.
mA
VVolts 2
mA Milliamperes 10
114.63 AI3 min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the minimum value for analog input AI3.
0.000 mA or V
-22.000 … 22.000 mA or V Minimum value of AI3. 1000 = 1 mA or
V
114.64 AI3 max (Visible only when parameter 114.0 1 Option
module 1 type is FIO-11.)
Defines the maximum value for analog input AI3.
10
-22.000 … 22.000 mA or V Maximum value of AI3. 1000 = 1 mA or
V
114.65 AI3 scaled at AI3 min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the real value that corresponds to the
minimum analog input AI3 value defined by
parameter 114.63 AI3 min.
0.000
-32768.000 … 32767.000 Real value corresponding to minimum AI3 value. 1 = 1
114.66 AI3 scaled at AI3 max (Visible only when parameter 114.0 1 Option
module 1 type is FIO-11.)
Defines the real value that corresponds to the
maximum analog input AI3 value defined by
parameter 114.64 AI3 max. See the drawing at
parameter 114.65 AI3 scaled at AI3 min.
100.000
-32768.000 … 32767.000 Real value corresponding to maximum AI3 value. 1 = 1
No. Name/Value/Range Description Default
FbEq (16b/32b)
