48 Parameters
114.45 AI2 unit selection (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Selects the unit for readings and settings related
to analog input AI2.
Note: This setting must match the corresponding
hardware setting on the I/O extension module
(see the manual of the I/O extension module).
The hardware setting is shown by parameter
114.44 AI2 HW switch pos.
mA
VVolts 2
mA Milliamperes 10
114.48 AI2 min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the minimum value for analog input AI2.
0.000 mA or V
-22.000 .. 22.000 mA or V Minimum value of AI2. 1000 = 1 mA or
V
114.49 AI2 max (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the maximum value for analog input AI2
10.000 mA or V
-22.000 … 22.000 mA or V Maximum value of AI2. 1000 = 1 mA or
V
114.50 AI2 scaled at AI2 min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the real value that corresponds to the
minimum analog input AI2 value defined by
parameter 114.48 AI2 min.
0.000
-32768.000 … 32767.000 Real value corresponding to minimum AI2 value. 1 = 1
114.51 AI2 scaled at AI2 max (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the real value that corresponds to the
maximum analog input AI2 value defined by
parameter 114.49 AI2 max. See the drawing at
parameter 114.50 AI2 scaled at AI2 min.
100.000
-32768.000 … 32767.000 Real value corresponding to maximum AI2 value. 1 = 1
114.56 AI3 actual value (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Displays the value of analog input AI3 in mA or V
(depending on whether the input is set to current
or voltage). This parameter is read-only.
-
-22.000 … 22.000 mA or V Value of analog input AI3. 1000 = 1 mA or
V
114.57 AI3 scaled value (Visible only when parameter 114.01 Option
module 1 type is FIO-11
.)
Displays the value of analog input AI3 after
scaling. See parameter 114.65 AI3 scaled at AI3
min. This parameter is read-only.
-
-32768.000 … 32767.000 Scaled value of analog input AI3. 1 = 1
No. Name/Value/Range Description Default
FbEq (16b/32b)
