Parameters 47
114.35 AI1 scaled at AI1 min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the real value that corresponds to the
minimum analog input AI1 value defined by
parameter 114.33 AI1 min.
0.0000
-32768.000 … 32767.000 Real value corresponding to minimum AI1 value. 1 = 1
114.36 AI1 scaled at AI1 max (Visible only when parameter 114.0 1 Option
module 1 type is FIO-11.)
Defines the real value that corresponds to the
maximum analog input AI1 value defined by
parameter 114.34 AI1 max. See the drawing at
parameter 114.35 AI1 scaled at AI1 min.
100.000
-32768.000 … 32767.000 Real value corresponding to maximum AI1 value. 1 = 1
114.37 RO2 source (Visible only when parameter 114.0 1 Option
module 1 type is FIO-01.)
Selects an inverter signal to be connected to relay
output RO2. For the available selections, see
parameter 114.11 DIO1 output source.
Off
114.41 AI2 actual value (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Displays the value of analog input AI2 in mA or V
(depending on whether the input is set to current
or voltage). This parameter is read-only.
-
-22.000 … 22.000 mA or V Value of analog input AI2. 1000 = 1 mA or
V
114.42 AI2 scaled value (Visible only when parameter 114.0 1 Option
module 1 type is FIO-11.)
Displays the value of analog input AI2 after
scaling. See parameter 114.50 AI2 scaled at AI2
min. This parameter is read-only.
-
-32768.000 … 32767.000 Scaled value of analog input AI2. 1 = 1
114.44 AI2 HW switch pos (Visible only when parameter 114.0 1 Option
module 1 type is FIO-11.)
Shows the position of the hardware
current/voltage selector on the I/O extension
module.
Note: The setting of the current/voltage selector
must match the unit selection made in parameter
114.45 AI2 unit selection.
-
VVolts 2
mA Milliamperes 10
No. Name/Value/Range Description Default
FbEq (16b/32b)
