46 Parameters
114.27 AI1 scaled value (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Displays the value of analog input AI1 after
scaling. See parameter 114.35 AI1 scaled at AI1
min. This parameter is read-only.
-
114.29 AI1 HW switch position (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Shows the position of the hardware
current/voltage selector on the I/O extension
module.
Note: The setting of the current/voltage selector
must match the unit selection made in parameter
114.30 AI1 unit selection.
mA
mA milliamperes 0
V voltage 1
114.30 AI1 unit selection (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Selects the unit for readings and settings related
to analog input AI1.
Note: This setting must match the corresponding
hardware setting on the I/O extension module
(see the manual of the I/O extension module).
The hardware setting is shown by parameter
114.29 AI1 HW switch position.
mA
mA milliamperes 0
V voltage 1
114.31 RO status (Visible only when parameter 114.01 Option
module 1 type is FIO-01.)
Status of relay outputs on the I/O extension
module. Example: 00000001b = RO1 is
energized, RO2 is de-energized.
-
0000h…FFFFh Status of relay outputs 1 = 1
114.33 AI1 min (Visible only when parameter 114.01 Option
module 1 type is FIO-11.)
Defines the minimum value for analog input AI1.
0.000 mA or V
-22.000 … 22.000 mA or V Minimum value of AI1. 1000 = 1 mA
or V
114.34 RO1 source (Visible only when parameter 114.01 Option
module 1 type is FIO-01.)
Selects an inverter signal to be connected to relay
output RO1.
For the available selections, see parameter
114.11 DIO1 output source.
Off
114.34 AI1 max (Visible only when parameter 114.01
Option
module 1 type is FIO-01 or FIO-11.)
Defines the maximum value for analog input AI1.
10.000 mA or
V
-22.000 … 22.000 mA or V Maximum value of AI1. 1000 = 1 mA
or V
No. Name/Value/Range Description Default
FbEq (16b/32b)
