Parameters 55
130.66 P(f) release time Sets the waiting time before releasing the power
limit. The timer is started after the frequency
drops below the release frequency.
0 s
0 … 600 s 1 = 1 s
130.67 P(f) release ramp Sets the ramp that is used after releasing the
power limit.
10%/min
0 … 600%/min 1 = 1%/min
130.68 P(f) release ramp ref Sets the P(f) limiter's release ramp reference. Nominal
Nominal Ramp reference is relative to nominal power. 1
Corner power Ramp reference is relative to corner power. 2
Pdelta Ramp reference is relative to corner power minus
release power.
3
130.69 P(f) activation delay Sets the waiting time before the Active power
limitation function is activated.
Note: Default setting is 0 ms except for Italy when
3000 ms is used.
0 ms
0...5000 ms Time 1 = 1 ms
130.70 Connect limit type Selects the active power ramping type after
connecting to grid.
Off
Off No active power ramping after grid connection. 0
After grid fault Power ramping is active only after grid fault. 1
Always Power ramping is active always when connecting
to grid.
2
130.71 Connect limit ramp Sets the active power ramp that is used after
connecting to grid.
10%/min
0 … 600%/min 1 = 1%/min
130.72 Grid fault ramp Sets the ramp that is used in reconnection after
grid fault.
10%/min
0 … 600%/min Ramp value. 1 = 1%/min
130.75 External power limit Sets the active power limit. Parameter for
externally controlled power limit.
200%
0 … 200% 1 = 1%
130.76 P(U) limiter Activates P(U) limitation function. Disable
Disable 0
Enable 1
130.77 P(U) trigger level Sets the voltage level where power limitation is
triggered.
110%
0 … 200% 1 = 1%
130.78 P(U) release level Sets the voltage level where power limitation is
released.
110%
0 … 200% 1 = 1%
130.79 P(U) limit level Sets the limited power level. 20%
0 … 100% 1 = 1%
130.80 P(U) limit ramp Sets the ramp down after power limit triggering. 50%/min
0 … 100%/min 1 = 1%/min
No. Name/Value/Range Description Default
FbEq (16b/32b)
