Parameters 73
158.12 CRC errors Contains the count of CRC error messages
received by the device. This is an indicator of
noise on the RS485 bus.
0
0 … 4 294 967 295 - / 1 = 1
158.17 Transmit delay Defines a minimum response delay in addition to
any fixed delay imposed by the protocol.
Note: Changes are effective only when settings
are refreshed or the device is power cycled.
0
158.33 Addressing mode Defines the mapping between parameters and
holding registers in the upper Modbus register
range (101... 65536).
Note: Changes are effective only when settings
are refreshed or the device is power cycled.
7
Mode 1 Only 16bit access is possible for parameter
groups 1... 255, indexes 1... 255.
RegisterAddress = 256*ParamGroup +
ParamIndex.
Note: This mode does not allow access to 32-bit
parameter values.
1
Mode 6 Both 16bit and 32bit access is possible for
parameter groups 101... 199, indexes 1... 99.
RegisterAddress for 16bit access =
100*(ParamGroup - 100) + ParamIndex.
RegisterAddress for 32bit access = 20000 +
200*(ParamGroup - 100) + 2*ParamIndex.
6
Mode 7 Only 32bit access is possible for parameter
groups 101... 227, indexes 1... 255.
RegisterAddress = 512*(ParamGroup - 100) +
2*ParamIndex.
Note: Only this mode can access all parameter
values.
7
158.34 Word order Selects the order in which 16-bit registers of 32-
bit parameters are transferred.
Note: Changes are effective only when settings
are refreshed or the device is power cycled.
LO-HI
HI-LO First register contains high order word and
second register contains low order word.
0
LO-HI First register contains low order word and second
register contains high order word.
1
158.101 Data I/O 1 Selects and maps any internal parameter of the
inverter to Modbus RTU holding register address
0. Allows the user to define/redefine the mapping
scheme that can suit the required Modbus RTU
master.
See the parameters list and mappings in chapter
Product name and serial number on page 107.
-
... ... ... ...
158.169 Data I/O 69 See parameter 158.101 Data I/O 1 -
No. Name/Value/Range Description Default
FbEq (16b/32b)
