ABB ProcessMaster 300 - Temperature Data Zone 1; Div. 1

Ex relevant specifications for operation in Div. 1
SM/FEX300/FEX500/FM/CSA-EN FEX300, FEX500 EN - 25
5.3 Temperature data for operation in Zone 1 / Div. 1
Model name Surface temperature
FEP315 / FEH315
FEP515 / FEH515
70 °C (158 °F)
FEP325 / FEP525 85 °C (185 °F)
FET325 / FET525 70 °C (158 °F)
The surface temperature depends on the fluid temperature.
With increasing fluid temperature > 70 °C (158 °F) or > 85 °C (185 °F) the surface temperature also increases to the level of the fluid
temperature.
Note
The maximum permissible fluid temperature depends on the lining and flange material, and is limited by the operating values in Table 1 and the
explosion protection specifications in Tables 2 ... n.
Table 1: Fluid temperature as a function of lining and flange material
Models FEP315 / FEP325, FEP515 / FEP525
Materials Fluid temperature (operating values)
Lining Flange Minimum Maximum
Hard rubber Steel
-10 °C (14 °F)
-5 °C (23 °F)
1)
90 °C (194 °F)
80 °C (176 °F)
1)
Hard rubber Stainless steel
-15 °C (5 °F)
-5 °C (23 °F)
1)
90 °C (194 °F)
80 °C (176 °F)
1)
Soft rubber Steel -10 °C (14 °F) 60 °C (140 °F)
Soft rubber Stainless steel -15 °C (5 °F) 60 °C (140 °F)
PTFE Steel -10 °C (14 °F) 130 °C (266 °F)
PTFE Stainless steel -25 °C (-13 °F) 130 °C (266 °F)
PFA Steel -10 °C (14 °F) 180 °C (356 °F)
PFA Stainless steel -25 °C (-13 °F) 180 °C (356 °F)
Thick PTFE Steel -10 °C (14 °F) 180 °C (356 °F)
Thick PTFE Stainless steel -25 °C (-13 °F) 180 °C (356 °F)
ETFE Steel -10 °C (14 °F) 130 °C (266 °F)
ETFE Stainless steel -25 °C (-13 °F) 130 °C (266 °F)
1) Only China production site
Models FEH315, FEH515
Lining Process connection Material Fluid temperature (operating values)
Minimum Maximum
PFA Flange Stainless steel -25 °C (-13 °F) 180 °C (356 °F)
PFA Wafer type - -25 °C (-13 °F) 130 °C (266 °F)
PFA Variable process connection Stainless steel -25 °C (-13 °F) 130 °C (266 °F)
