7 - Operation
LED status Operating state
green:
yellow:
red:
• Ventilation anomaly
Indicates ananomaly in the operation of the internal ventilation system that could limit output
power at high ambient temperatures.
• Overvoltage surge arresters triggered
Indicates that any class II overvoltage surge arresters installed on the AC or DC side have
been triggered
• Autotest not executed (only for Italian network standards)
On the inverter was not performed the Autotest
• Internal statistics memory anomaly
Indicates an operating anomaly in the internal memory on which the inverter statistics are
stored
• Buffer battery discharged
The buffer battery is low and the inverter does not maintain the time setting
green:
yellow:
red:
• Initial conguration failure
The inverter is in locked state due to a failure in the initial conguration of the equipment,
such as the standard network setting for the country of installation
• Self-test not carried out (for Italian grid standards only)
Self-test operation failure
Incompatibility of the device rmware versions
The rmware versions of the various devices comprising the equipment are incompatible
and are being updated (this is an automatic operation)
•Temperature sensor anomaly detected
green:
yellow:
red:
Updating the rmware from an SD card
The equipment rmware is being updated from an SD card
* lighting of
the LEDs in
sequence
Firmware programming failure
There has been a failure in programming the rmware, of one or more internal devices of the
equipment, to the equipment from an SD card.
green:
yellow:
red:
Updating the rmware from an SD card completed
The equipment rmware has been successfully updated from an SD card
green:
yellow:
red:
Updating the rmware from an SD card has failed
The equipment rmware update from an SD card has failed
*blink 3 times
green:
yellow:
red:
Remote OFF activated
The Remote Off command has been activated.
The unit will not connect to the network until the remote ON command has been activated
