2 - Characteristics
Table: Technical Data PVS-50-TL
Output overvoltage protection - Modular surge
arrester
Type II
Operating performance
Maximum Efciency (ηmax) 98.4%
Weighted Efciency (EURO/CEC) 98.2% / -
Communication
Embedded communication interface 2x RS485, 2x Ethernet (RJ45), WLAN (IEEE802.11 b/g/n @ 2,4 GHz)
Communication protocol Modbus RTU / TCP (Sunspec compliant); Aurora Protocol
Remote Monitoring services Standard level access to Aurora Vision monitoring portal
Advanced features
Integrated Web User Interface; Display (option); Embedded logging
and direct transferring of data to Cloud
Environmental
Ambient temperature range -25...+60°C (-13...140°F) with derating over 45°C (113°F)
Relative Humidity 4…100 % condensing
Typical noise emission pressure 75 dB(A) @ 1 m
Maximum operating altitude 4000 m (13123 ft) with derating above 2000 m / 6561 ft
Environmental pollution degree
classication for external environments
3
Environmental class Outdoor
Physical
Environmental Protection Rating IP 65 (IP54 for the cooling section)
Cooling System Forced air
Dimensions (H x W x D) 750 mm x 1100 mm x 257 mm / 29.5” x 43.3” x 10.12”
Weight 70 kg / 154 lbs (SX version)
Assembly System Mounting bracket (vertical or horizontal)
Overvoltage rating as per IEC 62109-1 II (DC input) III (AC output)
Safety
Safety class I
Isolation Level Transformerless (TL)
CE Marking CE
(5)
Safety and EMC Standards
IEC/EN 62109-1, IEC/EN 62109-2, EN 61000-6-2,
EN 61000-6-3, EN 61000-3-11, EN 61000-3-12
Grid standard (check the availability with your
sales channel)
CEI 0-21, CEI 0-16, DIN V VDE V 0126-1-1,
VDE-AR-N 4105, G59/3, EN 50438 (not for all national appendices),
RD 1699, RD 413, RD 661, P.O. 12.3, AS 4777, BDEW, NRS-097-
2-1, MEA, PEA, IEC 61727,
IEC 60068, IEC 61683, VFR-2014, IEC 62116
Accessories
PVS-50/60-GROUNDING KIT Allows to connect the negative input pole to ground
DISPLAY Display is available as optional by dedicated part number
1. The output voltage range may vary according to the grid standard of the country of installation
2. The output frequency range may vary according to the grid standard of the country of installation
3. In the event of a fault, limited by the external protection envisaged on the AC circuit
4. Please refer to the document “String inverters – Product manual appendix” available at www.abb.com/solarinverters for informa-
tion on the quick-t connector brand and model used in the inverter.
5. 50Hz only
6. Maximum installable size 20A
Note. Features not specically mentioned in this data sheet are not included in the product
