Description Parameter
(channel 504)
R, W, P Value
User-defined register 12 504V12 R, W 0...65535
a)
User-defined register 13 504V13 R, W 0...65535
a)
User-defined register 14 504V14 R, W 0...65535
a)
User-defined register 15 504V15 R, W 0...65535
a)
User-defined register 16 504V16 R, W 0...65535
a)
Unit address of the relay 504V200 R, W 1...254
Data transfer rate (Modbus),
kbps
504V201 R, W 9.6/4.8/2.4/1.2/0.3
Modbus link parity 504V220 R, W 0 = even
1 = odd
2 = no parity
CRC order of Modbus RTU link 504V221 R, W 0 = low/high
1 = high/low
a)
The default value is 0.
Parameters for DNP 3.0 remote communication protocol
Table 5.1.17.-14 Settings
Description SPA
parameter
(channel 503)
R, W Value range Default Explanation
Unit address 503V1 R, W 0...65532 1 Address of the relay in the DNP 3.0
network
Master address 503V2 R, W 0...65532 2 Address of the master station (destination
address for unsolicited responses)
Primary data link timeout 503V3 R, W 0 = no data link
timeout used
1...65535 ms
0 Used when the relay sends data using
service 3
Primary data link layer
retransmission count
503V4 R, W 0...255 0 Number of retransmissions on data link
layer
Application layer
confirmation timeout
503V6 R, W 0...65535 ms 5000 Used when the relay sends messages
with confirmation request
Application layer
retransmission count
503V7 R, W 0...255 0 Number of retransmissions on the
application layer when the relay sends
messages with confirmation request
Confirmation on application
layer
503V9 R, W 0 = enabled only
for event
messages
1 = enabled for all
messages
0 Used to enforce inclusion of confirmation
request in all application messages
(DNP 3.0 standard requires inclusion of
confirmation request in event messages
only)
Default variation of binary
input objects
503V10 R, W 1...2 2
Default variation of binary
input change event objects
503V11 R, W 1...2 2
Default variation of analog
input objects
503V15 R, W 1...4 2
Default variation of analog
input change event objects
503V16 R, W 1...4 2
