ABB REF615 J User Manual

Name Type Default Description
IN6 BOOLEAN 0=False Input 6 status
IN7 BOOLEAN 0=False Input 7 status
IN8 BOOLEAN 0=False Input 8 status
Table 130: TOFGAPC Output signals
Name Type Description
Q1 BOOLEAN Output 1 status
Q2 BOOLEAN Output 2 status
Q3 BOOLEAN Output 3 status
Q4 BOOLEAN Output 4 status
Q5 BOOLEAN Output 5 status
Q6 BOOLEAN Output 6 status
Q7 BOOLEAN Output 7 status
Q8 BOOLEAN Output 8 status
3.14.4.4 Settings
Table 131: TOFGAPC Non group settings
Parameter
Values (Range) Unit Step Default Description
Off delay time 1 0...3600000 ms 10 0 Off delay time
Off delay time 2 0...3600000 ms 10 0 Off delay time
Off delay time 3 0...3600000 ms 10 0 Off delay time
Off delay time 4 0...3600000 ms 10 0 Off delay time
Off delay time 5 0...3600000 ms 10 0 Off delay time
Off delay time 6 0...3600000 ms 10 0 Off delay time
Off delay time 7 0...3600000 ms 10 0 Off delay time
Off delay time 8 0...3600000 ms 10 0 Off delay time
3.14.4.5 Technical data
Table 132: TOFGAPC Technical data
Characteristic
Value
Operate time accuracy ±1.0% of the set value or ±20 ms
Section 3 1YHT530004D05 D
Basic functions
124 615 series
Technical Manual

ABB REF615 J Specifications

General

Type	Feeder Protection Relay
Nominal Frequency	50/60 Hz
Rated Current	1 A / 5 A
Binary Outputs	Up to 8
Communication Protocols	IEC 61850, Modbus, DNP3
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault, Under/Over voltage
Operating Temperature	-25°C to +55°C
Ingress Protection	IP54
Weight	Approximately 1.5 kg
