5.7.7 Settings
Table 494: UPSCBR Non group settings
Parameter Values (Range) Unit Step Default Description
Operation 1=on
5=off
1=on Operation Off / On
CB open hold delay 300...500 ms 1 300 CB open hold delay time
Operate pulse time 100...20000 ms 1 100 Operate pulse time
Signal pwr on delay 300...500 ms 1 300 Signal power on delay time
5.7.8 Technical data
Table 495: UPSCBR Technical data
Characteristic Value
Operate time accuracy ±1.0% of the set value or ±20 ms
1YHT530004D05 D Section 5
Protection related functions
615 series 569
Technical Manual
