ABB REF615 J User Manual

3.14.9.4 Settings
Table 149: SPCGGIO Non group settings
Parameter Values (Range) Unit Step Default Description
Loc Rem restriction 0=False
1=True
1=True Local remote switch restriction
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 1
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 2
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 3
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 4
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 5
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 6
Generic control point description
Operation mode 0=Pulsed
1=Toggle
-1=Off
-1=Off Operation mode for generic control point
Pulse length 10...3600000 ms 10 1000 Pulse length for pulsed operation mode
Description SPCGGIO1
Output 7
Generic control point description
Table continues on next page
Section 3 1YHT530004D05 D
Basic functions
136 615 series
Technical Manual

ABB REF615 J Specifications

General

Type	Feeder Protection Relay
Nominal Frequency	50/60 Hz
Rated Current	1 A / 5 A
Binary Outputs	Up to 8
Communication Protocols	IEC 61850, Modbus, DNP3
Mounting	Flush mounting
Protection Functions	Overcurrent, Earth fault, Under/Over voltage
Operating Temperature	-25°C to +55°C
Ingress Protection	IP54
Weight	Approximately 1.5 kg
