ABB RETA-02 - PROFIdrive Profile-Specific Parameters

Communication
93
I&M3 Additional data
I&M4 Signature
PROFIdrive profile-specific parameters
PROFIdrive parameters contain data of the drive in standard form.
The table below describes the supported PROFIdrive parameters.
Content Size Description
Header 10 bytes -
DESCRIPTOR 54 bytes Any additional data set by the user
Content Size Description
Header 10 bytes -
SIGNATURE 54 bytes Security code for identifying sessions and changes
Para-
meter
Mode
***
R/W
*
Data type Description
915 V/P R Array [10]
Unsigned16
Assignment PZD1 to PZD10 in
setpoint telegram
916 V/P R/ Array [10]
Unsigned16
Assignment PZD1 to PZD10 in actual
value telegram
919 V/P R Visible String16 Device system number.
922 P R Unsigned16 Telegram selection
923 P R Array[n]Unsigned16 List of all parameters for signals
927 V/P R/W Unsigned16 Operator control rights
Value Mode
0 Parameters cannot be
written, only read (927
can be written)
1 Parameters can be
written and read
(default).
