Explosion-protection safety precautions

42/68-167-EN RHDE250 ... 4000 (Contrac) 11

Pos: 6.1 /Überschri ften/1/A - F/Ex-techni sche Sicherheitshin weise @ 9\mod_118141641 5484_3101.doc @ 102826

2 Explosion-protection safety precautions

Pos: 6.2 /Ex-technisc he Sicherheitshinw eise/Aktorik/Antr iebe/Elektr. Sc hwenkantriebe/Allge mein/Bauliche Veränder ungen @ 12\mod_11891629 87125_3101.doc @ 121248

als

Important

Technical modifications to the actuator or motor cancel the explosion protection.

• Before installing the actuator, review the information on the ID label regarding device class,

Ex category, Ex zone and temperature class to make sure the actuator is approved for

operation in the relevant hazardous area. In the event of deviations, the actuator may not be

put into operation.

• Check the oil level and mounting position prior to commissioning the device in explosive

atmospheres.

• Only use levers for the shaft that are specified by the manufacturer. Use of other levers

requires ATEX certification.

Important

Read the information in chapter Installation with additional drive elements, page 1

Pos: 6.3 /Überschri ften/1.1/1-spalti g/A - F/Betrieb am Frequenzu mformer @ 10\mod_11815 65595390_3101.doc @ 102922

2.1 Operation via frequency transformer

Pos: 6.4 /Ex-technisc he Sicherheitshinw eise/Aktorik/Antr iebe/Allgemein/Be trieb am Frequenzumfor mer @ 9\mod_118141604598 4_3101.doc @ 102803

• The frequency converter (electronic unit) may not installed or used within the hazardous

area.

• Check whether the electronic unit is loaded with the parameters of the actuator it is

connected to.

• Check the electronic unit for proper connection to the correct actuator.

• Setpoint monitoring is activated as default setting when the electronic unit leaves the

manufacturer. Do not de-activate this setting.

• Rapid traverse mode is not allowed on Ex actuators, and the feature cannot be activated

from the user interface.

• The Contrac power electronic unit must be upstream from the motor temperature monitoring

unit SD241B or similar, certified tripping unit.

Pos: 6.5 /Überschri ften/1.1/1-spalti g/S - Z/Vermeidung elek trostatischer Auf ladung @ 12\mod_1189586171 265_3101.doc @ 121586

2.2 Preventing electrostatic charging

Pos: 6.6 /Ex-technisc he Sicherheitshinw eise/Aktorik/Antr iebe/Allgemein/Ver meidung elektrosta tischer Aufladung @ 12\ mod_1189585883609_31 01.doc @ 121563

Due to potential unallowed charging of the housing, the effects of high voltage sources on the

equipment must be prevented.

Important

Clean coated surfaces with a damp towel.
