User interface menus
Figure 63: Troubleshooting related menus in the user interface (digitally manipulated screen shot)
The following table represents the first 2 menu levels (see also User interface menus on page 39) of the graphical user interface as far
as the troubleshooting is concerned. Some of the subjects in Troubleshooting on page 31 refer to the user interface.
Use the numbering in table 5 to facilitate the navigation. The user interface software does not use any numbering in the menus.
A Operate
B Diagnosis
C Configure
D Service
A 1 Positioner
B 1 Status
C 1 General
D 1 Initial setting
A 2 Controller
B 2 Alarms / Failures
C 2 Operation
D 2 Test
B 3 Maintenance
C 3 End positioner
D 3 Signal simulation
B 4 Load
C 4 Input / Output
D 4 Calibration of analog
output
C 5 Monitoring
C 6 Controller
C 7 Actuator specific data
C 8 Data overview
