ABB RHD Series User Manual

Installation
16 RHDE250 ... 4000 (Contrac) 42/68-167-EN
Pos: 11.19 /Überschri ften/1.1/1-spa ltig/M - R/Montagebeispi el @ 10\mod_1181637256 390_3101.doc @ 103672
4.5 Mounting examples
Pos: 11.20 /Montage/A ktorik/Elektr. S chwenkantriebe/RHDE250. ..4000/Befesti gungselemente @ 10\mod _1181651331812_3101.d oc @ 104044
4.5.1 Fastening elements
RHDE250 RHDE500
RHDE800
RHDE1250
RHDE2500
RHDE4000
clamping screws for
mech. limit stop
tightening torque: 79 Nm
(58 Lbf-ft)
95 Nm
(144 Lbf-ft)
670 Nm
(494 Lbf-ft)
670 Nm
(494 Lbf-ft)
lever clamping screw
tightening torque: 79 Nm
(58 Lbf-ft)
195 Nm
(144 Lbf-ft)
390 Nm
(288 Lbf-ft)
390 Nm
(288 Lbf-ft)
Mounting screw
(property class 8.8)
tensile strength: 12 mm
(0.47 inch)
18 mm
(0.71 inch)
20 mm
(0.78 inch)
20 mm
(0.78 inch)
tensile strength:
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
≥ 800 N/mm
2
(≥ 116032
pounds/square
inch)
Yield strength
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
≥ 640 N/mm
2
(≥ 93550
pounds/square
inch)
