4.4 Charge session
4.4.1 Charge an EV
1. Park an EV in the parking space. Make sure that the connector of the EV charge
cable can reach the connector on the EV.
2. De-energize the EV.
3. Start the charge session. Refer to section 4.4.2 .
4. Stop the charge session. Refer to section 4.4.3 .
4.4.2 Start a charge session
1. On the touchscreen, select the applicable connector button.
Note: If you skip this step, the EVSE selects the correct connector
automatically when you connect the EV charge cable to the EV.
2. Remove the EV charge cable from the EVSE.
3. Connect the EV charge cable to the connector on the EV.
4. On the touchscreen, press the Start button.
5. If the touchscreen shows a message to authorize the charge session, do the
instruction that the touchscreen shows.
The EVSE charges the EV and shows the progress on the touchscreen.
4.4.3 Stop a charge session
1. On the touchscreen, press the
stop button.
Note: When the battery is full, the charge session stops automatically.
2. If the touchscreen shows a message to authorize the charge session, do the
instruction that the touchscreen shows.
3. Disconnect the EV charge cable from the EV.
Note: In some cases, the EV locks the connector to the EV. To unlock the
connector, obey the instructions for the EV.
4. Install the EV charge cable on the EVSE.
