7 Technical data
7.1 EVSE type
The EVSE type is a code.
The code is made out of 4 parts: T UV W
Code part Description Value Meaning of the value
T Brand Terra -
U Power rating 9 90 kW
12 120 kW
18 180 kW
V Design generation 4 Fourth generation
W EV charge cable
connection
C One CCS connection
CC Two CCS connec-
tions
CJ One CCS connection
and one ChadeMo
connection
Example
Terra 94 C:
• T = Terra, Brand = Terra
• U = 9, Power rating = 90 kW
• V = 4, Design generation = fourth generation
• W = C, EV charge cable connection = one CCS connection
7.2 General specifications
Parameter Specification
Compliance and safety CE
CHAdeMO 1.2
IP rating The type plate shows the specification. Re-
fer to section 2.1 .
IK rating according to IEC 62262: enclo-
sure
IK10
IK rating according to IEC 62262:
touchscreen
IK08
EMC rating Class B
