4.5 Energize the EVSE
1. Open the front door. Refer to section
6.1
.
2. Set the manual switch to the
1
position (vertical).
Warning:
General hazard
• Be careful and use both your hands to turn the manual switch. You
need some force to turn the switch.
3. Close the front door. Refer to section
6.2
.
The EVSE starts. The display shows a message when the EVSE is ready for
operation.
4.6 De-energize the EVSE
4.6.1 De-energize the EVSE - general procedure
Preliminary requirements
1. • Voltage tester
Procedure
1. Open the front door and right doors. Refer to section
6.1
.
2. Set the manual switch to the
0
position (horizontal).
Warning:
General hazard
• Be careful and use both your hands to turn the manual switch. The
manual switch turns quite arduous.
3. Wait until all the power modules are off:
• All the LEDs of the power modules are off.
• The fans stopped.
4. Measure the AC voltage. Refer to section
4.6.2
.
5. Make sure that all the measured voltages are 0 V.
6. Measure the DC voltage. Refer to section
4.6.3
.
7. Make sure that all the measured voltages are 0 V.
8. Close the doors. Refer to section
6.2
.
4.6.2 Measure the AC voltage
Preliminary requirements
1. • Only do this procedure if a
different procedure refers to
this procedure.
Operation
24 BCM.S1101.0-EN | 001
