Parameter Specification
Bandwidth, upload Minimum 128 kbit/s
Bandwidth, download Minimum 4 Mbit/s
Availability 99.9%
7.10 DC output specifications
7.10.1 General specifications
Parameter Specification
DC output voltage range, CCS 150-920 V DC
DC output voltage range, CHAdeMO 150-500 V DC
Minimum DC output current 15 A
Connection standard CHAdeMO 1.2
CCS
7.10.2 Terra 94
Parameter Specification
DC output power, mode 1, continuously on
one EV charge cable
Maximum 90 kW
Simultaneous DC on two outlets No. One DC output operates at a time.
Maximum DC output current, CCS or CHA-
deMO
200 A
Note:
• You can upgrade the EVSE to deliver 120 kW or 180 kW and enable
parallel charging on two EVs.
• You can install a different EV charge cable to increase the output current.
Technical data
