7.3 Maintenance schedule for the service engineer
Part name Years after startup
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Filter inlet kit - R R R R R R R R R R R R R R R
Filter outlet kit - R I R I R I R I R I R I R I R
Fan cabinet - I I I I R I I I I R I I I I R
Power module - I I I I I I I I I R I I I I I
DC fuse 200 A - I I I I R I I I I R I I I I R
CPI Combo CCS - I I I I I I I I I I I I I I R
CPI CHAdeMO - I I I I I I I I I I I I I I R
Touchscreen/
CPU
- I I I I I I I I I I I I I I R
DC outlet contac-
tor
- I I I I I I I I I I I I I I R
Power supply - I I I I R I I I I R I I I I R
CCS connector
and cable
- I I I I I I I I I I I I I I I
CHAdeMO con-
nector and cable
- I I I I I I I I I I I I I I I
Gun holders - I I I I I I I I I I I I I I I
• 'I' = Inspection or other procedure
• 'R' = Replacement
7.4 Spare parts
Part Name Part number Quantity
Air inlet filter XUF.N0001.0 4
Air outlet filter XUF.N0002.0 3
Cooling fan ZFV.V2N00.0 1
Power module YPA.00267 3 x Terra 94
4 x Terra 124
6 x Terra 184
DC fuse 500 A ZEG.00132 1 x Terra x4 C
2 x Terra x4 CC/CJ/JJ
CPI Combo CCS YVD.V39A3.0 1 x Terra x4 C/CJ
2 x Terra x4 CC
CPI CHAdeMO YVD.V39A6.0 1 x Terra x4 CJ
2 x Terra x4 JJ
Touchscreen/CPU YVD.V2N11.0 1
DC outlet contactor ZEQQ.00104 1 x Terra x4 C
2 x Terra x4 CC/CJ/JJ
Interlink contactor ZEQ.00124 2 x Terra x4 CC/CJ/JJ
