Output current in function of output voltage
A
100
0
100
200
300
400
500
600
200 300 400 500 600
B
700 800 900 1000
A Output current [A] B Output voltage [V]
Output power in function of output voltage
A
100
0
40
20
60
80
100
140
120
160
180
200
200 300 400 500 600
B
700 800 900 1000
A Output power [kW] B Output voltage [V]
