• Hook the inverter to the bracket
by inserting the head of the rear
screws in the slots as shown in
the gure. To make lifting easier,
handles
06
or eyebolts (M12) can
be attached to the side holes pro-
vided.
P
OWE
R
ALARM GFI
ESC
UP
DOWN ENTER
TRIO
01
09
02
07
03
POWER ALARM GFI
ESC UP
DOWN ENTER
TRIO
05
02
03
• Join the two parts by tightening
the coupling screw
05
working
from the lower part of the wiring
box.
