1. Address
This section of the menu allows you to set the address for the serial com-
munication of single inverters connected to the RS485 line.
The addresses that can be assigned are 2 to 63. Use the UP and DOWN
buttons to scroll the numerical scale.
At present, the ‘AUTO’ selection cannot be used
2. Display Set
This section of the menu allows you to set the timescale (8/16/24 hours)
for the power graph shown on the display
3. Service
This section of the menu is reserved for installers. To access this, it is
necessary to have a dedicated password which may be obtained from
the website https://registration.ABBsolarinverters.com.
Before connecting to the site, make sure you have all the information
required to calculate your password:
Inverter model
Serial Number and Week of Production
Update eld
When you have a password you can set the parameters in the menu.
Due to the variation of the above mentioned parameters it is possible that the disconnection
from the grid does not take place if the values exceed those mentioned in the standards of
the country of installation. If these parameters exceed the standard values, install an interface
protection, external to the inverter, which is compliant with the requirements of the country of
installation.
The table below shows the parameters and the range of values that may
be set:
Parameter Parameter description Setting range
Set U>> Grid Over-voltage (OV) threshold (extended range) Unom … Unom x 1.3
Set U<< Grid Under-voltage (UV) threshold (extended range) 10V … Unom
Set F>> Grid Over-Frequency (OF) threshold (extended range) Fnom … Fnom + 5Hz
Set F<< Grid Under-Frequency (UF) threshold (extended range) Fnom - 5Hz … Fnom
Set U> Grid Over-voltage (OV) threshold (strict range) Unom … Unom x 1.3
Set U> (10Min)
Grid Over-voltage (OV) threshold (measure of the averagevalue of the
mains voltage)
Unom … Unom x 1.3
Set U< Grid Under-voltage (UV) threshold (strict range) 10V … Unom
Set F> Grid Over-Frequency (OF) threshold (strict range) Fnom … Fnom + 5Hz
Set F< Grid Under-Frequency (UF) threshold (strict range) Fnom - 5Hz … Fnom
Set Uconn> Max voltage admissible during grid pre-connection phase Unom … Unom x 1.3
Set Uconn< Min voltage admissible during grid pre-connection phase 10V … Unom
Set Fconn> Max frequency admissible during grid pre-connection phase Fnom … Fnom + 5Hz
Set Fconn< Min frequency admissible during grid pre-connection phase Fnom - 5Hz … Fnom
Set Time U>> Intervention time of Over Voltage (U>>) protection 0 … 327670mS
Set Time U<< Intervention time of Under Voltage (U<<) protection 0 … 327670mS
Set Time F>> Intervention time of Over Frequency (F>>) protection 0 … 327670mS
Set Time F<< Intervention time of Under Frequency (F<<) protection 0 … 327670mS
