Parameter Parameter description Setting range
Set Time U> Intervention time of Over Voltage (U>) protection 0 … 327670mS
Set Time U< Intervention time of Under Voltage (U<) protection 0 … 327670mS
Set Time F> Intervention time of Over Frequency (F>) protection 0 … 327670mS
Set Time F< Intervention time of Under Frequency (F<) protection 0 … 327670mS
Set time conn 1 Time lag, of grid parameters control, before connection 0 … 65535mS
Set time conn 2 Time lag, of grid parameters control, before connection after grid fault 0 … 65535mS
Disable U>> U>> protection threshold disabling Enable/Disable
Disable U<< U<< protection threshold disabling Enable/Disable
Disable F>> F>> protection threshold disabling Enable/Disable
Disable F<< F<< protection threshold disabling Enable/Disable
Disable U> U> protection threshold disabling Enable/Disable
Disable U> (10Min) U> (10Min) protection threshold disabling Enable/Disable
Disable U< U< protection threshold disabling Enable/Disable
Disable F> F> protection threshold disabling Enable/Disable
Disable F< F< protection threshold disabling Enable/Disable
U> (10Min) Der. Enabling of power derating due to high average grid voltage value Enable/Disable
Slow Ramp Enabling gradual power immission into the grid after connection Enable/Disable
OF Derating Selection of power derating mode due to high value of grid frequency
0 Derating disable
1 Derating BDEW
2 Derating VDE-AR-N
3 Derating CEI
Reset Country S.
Unlocks the grid standard selection (resets the 24 hours available for
changing the grid standard)
Accept boards Allow to associate a new inverter board (when replacing)
4. New PW
This section of the menu allows you to change the password for access-
ing the settings menu (default 0000).
We ADVISE you to be very careful in memorizing the new password.
If the Password is misplaced, it will not be possible to access the inverter, since there is no
Reset function for security reasons.
5. Time
Allows you to set the current date and time (daylight saving time not
included)
6. Language
Allows you to set the required menu language
7. Vstart Set
This section of the menu allows you to set the Vstart voltage (separately
for both channels if they are congured in independent mode), to adapt it
to the requirements of the system.
We advise changing the activation voltage only if really necessary and to set it to the correct
value: the photovoltaic generator sizing instrument available on the Internet site of ABB indi-
cates whether it is necessary to change the Vstart and the value to set.
