Page #109 background imageLoading...
Page #109 background image
- 109 -
001003AG
7 - Operation
Description of the internal Webserver
The UNO-DM-TL-PLUS inverters are equipped with an advanced in-
tegrated webserver and user interface that allow a full access to all
conguration and comissioning parameters from any electronic device
(laptop, tablet and smartphone).
The screenshots shown in this chapter are indicatives and it could be changed without any
notication.
Access to the internal Webserver
To access to the internal webserver is required to connect a device equip-
ped with wireless connection (such as tablet, laptop or smartphone).
Depending on completion of STEP #2 of the wizard commissioning pha-
se (the inverter was connected to the domestic wireless network (“Sta-
tion Mode”), or this step was skipped) it’s required to follow one of the two
procedures described below:
Connection to the inverter in “Station Mode”
If the inverter was connected to the domestic wireless network, follow
this procedures:
• Enable the wireless connection on the device (tablet, smartphone or
laptop) and connect it to the same wireless network to which the inverter
is connected.
• Open an internet browser (reccomended browser: Chrome versions
from v.55, Firefox versions from v.50) and enter the IP Address assigned
by the router to the inverter, or the “Host Name” (that could be obtained
writing this url: http://ABB-XX-XX-XX-XX-XX-XX.local replacing the
Xwith the hex digits of the wireless MAC address of the inverter (it can
be found on the “Wireless Identication Label” placed on the side of the
inverter or applied during the commissioning phase to the quick installa-
tion guide on cover page)), to access the login page.
In order to use the “Host Name” as an alternative to the dynamic IP address, the Wi-Fi router
to which the board is connected (when operating in “Station Mode”) must provide the Domain
Name System (DNS) service (contact the network administrator for further information regar-
ding the presence or absence of the DNS service in the Wi-Fi router or how to enable it). In this
way, even if the IP address assigned to the inverter should change over time, (dynamic IP), it
will always be possible to use the same “Host Name” which will remain unchanged over time.
Android devices doesn’t allow the use of “Host Name” to access to the internal webserver!
The IP address assigned may vary for reasons connected to the wireless home router setup
(for example, a very brief DHCP lease time). If verication of the address is required, it is
usually possible to obtain the client list (and the corresponding IP addresses) from the wire-
less router administration panel.
