01
, Bracket
03
, Heat sink
04
, Anti-condensation valve
05
, Front cover
06
, LED panel
09
, DC input connectors
10
, AC output connector
11
, Wireless antenna connector
12
, DC Input terminal block
13
, Locking Screw
16
,
DC disconnect switch (Only for -S models)
18
,
UNO-DM-COM KIT Card
(Only for -X or as optional accessory)
19
, External earth connection
20
, Service cable glands
Reference number index
Graphical representation of references
03
09 04 16 10 11 2019
01
13
03
01
13
18
13
06
05
12
