- 33 -
000984AG
3 - Characteristics
Bracket dimensions
The dimensions of the wall mounting bracket are expressed in
mm.
53.4
322
8
8
80 24.523.5
9.3 33.25 86.75 86.7531.75 31.75
8
8
A
A
50.25
SIDE VIEW
SECTION VIEW (A-A)
128
