- 23 -
000983AG
1- Introduction and general information
Accessory Board UNO-DM-PLUS-COM Ethernet KIT
(optional accessory)
21
25
24
26 27
23
22
21
, Inverter connector
22
, RS485 Termination line jumper
23
, DRM0 activation jumper
24
, ALARM terminal block
25
, Fixing hole
26
, RS485 and REM terminal block
27
, LAN Ethernet connector
