- 22 -
000983AG
1- Introduction and general information
21
, Inverter connector
22
, RS485 Termination line jumper
23
, DRM0 activation jumper
24
, ALARM terminal block
25
, Fixing hole
26
, RS485 and REM terminal block
Accessory Board UNO-DM-COM KIT
(Equipped on -X models or optional accessory)
K1
J1
COM
NC NO
J4
21
25
24
26
23
22
