ABB UNO-DM-1.2-TL-PLUS-Q User Manual

- 27 -
000984AG
3 - Characteristics
UNO-DM-1.2 UNO-DM-2.0 UNO-DM-3.0
Communication
Embedded Communication Interface Wireless
(5)
Embedded Communication Protocol ModBus TCP (SunSpec)
Optional Communication protocol ModBus RTU (SunSpec) , Aurora Protocol
Commissioning tool Web User Interface, Aurora Manger Lite
Firmware Update Capabilities Locally and remotely
Monitoring
Plant Portfolio Manager, Plant Viewer, Plant Viewer for Mobile
(7)
,
ABB Ability™ for solar plants - Energy Viewer
Optional board UNO-DM-COM kit
Optional communication interface
RS485 (use with meter for dynamic control of the network
input), alarm relay / load manager, remote On / Off
Optional communication protocol ModBus RTU (SunSpec), protocol Aurora
Optional board UNO-DM-PLUS Ethernet COM kit
Optional communication interface
Ethernet, RS485 (use with meter for dynamic control of the
network input), alarm relay / load manager, remote On / Off
Optional communication protocol
ModBus TCP (SunSpec), ModBus RTU (SunSpec), Proto-
col Aurora
Environmental
Ambient temperature range
-25...+60°C /-13...140°F
with derating above 50°C/122°F
Relative humidity 0...100 % condensing
Acoustic noise emission level 50 dBA @ 1 m
(10)
Maximum operating altitude without derating 2000 m / 6560 ft
Classication of the degree of environmental pollution by
external environment
3
Environmental category
External
Physical
Environmental protection rating IP 65
Cooling Natural
Dimension (H x W x D) 553mm x 418mm x 175mm / 21.8” x 16.5” x 6.9”
Weight 15 kg / 33 lb
Mounting system Wall bracket
Overvoltage category according to IEC 62109-1
II (DC input) III (AC output)
Safety
Isolation level Transformerless
Marking CE, RCM
Safety class
I
Safety and EMC standard
IEC/EN 62109-1, IEC/EN 62109-2, AS/NZS 4777.2,
EN 61000-6-1, EN 61000-6-2, EN 61000-6-3,
EN 61000-6-4, EN 61000-3-2, EN 61000-3-3,
Grid standard
(9)
(check your sales channel for availability)
CEI 0-21, DIN V VDE V 0126-1-1, VDE-AR-N 4105,
G83/2, G59/3, RD 413, ITC-BT-40, AS/NZS 4777.2,
IEC 61727, IEC 62116
1. Refer to the document “String inverter – Product Manual appendix” available at www.abb.com/solarinverters to know the brand
and the model of the quick t connector.
2. For UK G83/2 grid standard, maximum output current limited to 16A up to a maximum output power of 3600W and maximum
apparent power of 3600 VA.
3. The AC voltage range may vary depending on specic country grid standard
4. The Frequency range may vary depending on specic country grid standard.CE only for 50Hz.
5. As per IEEE 802.11 b/g/n standard
7. Plant Viewer for Mobile availble remotely only, not for local commissioning
8. Pacr = 4200 W @ 45°C/113°F
9. Further grid standard will be added, please refer to ABB Solar page for further details.
10. @ Pure sine wave condition.
Note. Features not specically listed in the present data sheet are not included in the product
