XIO USER MANUAL | 2106424MNAB | 91
Figure 4-80: Configure measurement value registers for measurement application
NOTE: Configure other applications as required. Application configuration details
are beyond the scope of this manual. Application
-specific topics are available on each application
Help on the for specific topics.
4.9 Configure the I/O Interface for TFIO module support
The XIO supports I/O expansion with TFIO modules. This section provides steps to connect the TFIO
modules and to add and configure the I/O Interface application. The I/O Interface application manages
the communication with the modules.
For additional details supporting TFIO modules, see the link to the I/O
Interface Application Guide
listed in Additional information, or click Help
on any of the I/O Interface
screens in PCCU for specific configuration information.
