Table 8. Guidance and Manufacturer’s Declaraon – Electromagnec Immunity
Immunity Test IEC 60601 Test Level Compliance Level Electromagnec Environment
Guidance
Electrostac discharge (ESD)
IEC 61000-4-2
±8 kV contact
±15 kV air
±8 kV contact
±15 kV air
The relave humidity should be
at least 15%.
Electrical fast transient/burst
IEC 61000-4-4
±2 kV for power supply lines
±1 kV for input/output lines
Not applicable No guidance for baery‑powered
devices.
Surge
IEC 61000-4-5
±1 kV line to line
±2 kV line to ground
Not applicable No guidance for baery‑powered
devices.
Voltage dips, short interrupons
IEC 61000-4-11
<5% U
T
40% U
T
70% U
T
Not applicable No guidance for baery‑powered
devices.
Power frequency
(50/60 Hz) magnec eld
IEC 61000-4-8
30 A/m 30 A/m Power frequency magnec elds
should be at levels characterisc
of a typical locaon in a typical
commercial or hospital
environment.
Conducted RF IEC 61000-4-6 3 Vrms
150 kHz to 80 MHz
3 Vrms The device is intended for use in
the electromagnec environment
in which radiated RF disturbances
are controlled. The customer or
the user of the device can help
prevent electromagnec
interference by maintaining a
minimum distance between
portable and mobile RF
6 Vrms (ISM/Radio bands
between 150 kHz to 80 MHz)
80% AM at 1 kHz
6 Vrms
