ABEM Terraloc Pro 2
9
2 Overview of the Instrument
The Connector Panel
All connectors except for the external power are situated on the right side panel of the
Terraloc Pro 2 (Figure 2). Some of the connectors are described in more detail in chapter
10 Appendix B. Connectors.
Note! Always have the connector protection dust caps in
place whenever a connector is not used
Figure 2 The Connector panel
