abem Terraloc Pro 2 - Page 91

ABEM Terraloc Pro 2
89
Post recording features
Digital filters
Band-pass, low-pass, high-pass, band-reject and
remove DC offset
Spectrum analysis
Any single trace, FFT analysis
Velocity Analysis
On-screen analysis of refractor velocity
First-arrivals picking
Automatic or manual. Times can be saved with
record.
Pre-stack correlation
Yes, cross correlation with reference or any other ch.
Processor, RAM and hard disk
Processor
Low power Intel Atom with 4 cores of 1.9 GHz
Operating System
Linux Lubuntu
Internal RAM
4 GB
Hard disk capacity
at least 100 GB
Display
8,4“ Active TFT LCD, full color, daylight visible, 800x600
I / O port
3 x USB 2.0 ports
Network interface
1 x IEEE 802.3 TP-10/100/1000 (RJ-45 IP67)
Built-in WLAN Antenna in handle
