CAT 3 1 Identification

1 Identification

The CAT 3 robot mount is used in industry and the trade for connecting the

robot and the tool. The CAT 3 is a three-dimensionally acting safety cut-out that

is adaptable to all types of robots and handling machines via a connecting

flange. These operating instructions describe the robot mount CAT 3 only. The

CAT 3 robot mount must only be operated using original ABICOR BINZEL

spare parts.

* Not included in the CAT 3 delivery.

1 Torch neck*

2 Torch mount*

3 Helix cable

4 Bracket*

5 Cable assembly*

6 CAT 3

7 Robot*

8 Connecting flange*

Fig. 1 Overview
