3 Product description CAT 3
3.2 Abbreviations
3.3 Nameplate
The CAT 3 is labelled as follows:
When making inquiries, please note the following information:
• Date of Manufacture
• Serial number
3.4 Signs and symbols used
The following signs and symbols are used in the operating instructions:
Unit of measurement in drawings or diagrams Millimeters [mm]
Tab. 9 Dimensions
1 CAT 3 2 Nameplate 3 Date of Manufacture 4 CAT 3 serial number
Fig. 5 Nameplate
Symbol Description
• Bullet symbol for instructions and lists
Cross reference symbol refers to detailed, supplementary or further information
1 Step(s) described in the text to be carried out in succession
