Ins p ect i o n | Tes t l og b o o k
41
LOAD HOOK AND SUSPENSION BRACKET
Hook designation
DIN 15401 (see “Checking the load hook”, page 32)
Type Single load hook
Maximum load capacity see label on front
Classification according to FEM see label on front
Material
(see “Checking the load hook”, page 32)
Test interval at least once annually
Maximum opening width
(see “Checking the load hook”, page 32)
Minimum base height
(see “Checking the load hook”, page 32)
Minimum bracket thickness
(see “Checking the suspension bracket”, page 32)
Inspected on
by
Designation
Measurement
‘e’ [mm]
Measurement
‘f’ [mm]
Measurement
‘g’ [mm]
Load capacity
[kg]
Remarks
