Ge ne r a l i n for m a tio n | T h e c hai n hoi s t
12
GM8 800.16-1, 1000.12-1,
1250.10-1, 1600.8-1, 1600.8-
2,
2000.6-2, 2500.5-2 and
3200.4-2
Operating
voltage
220 –
240 V
380 –
415 V
460 –
500 V
Mains frequency 50 Hz 50 Hz 50 Hz
Duty cycle 40 % 40 % 40 %
Switching rate 240 c/h 240 c/h 240 c/h
Rated power 0.4
2.50
0.4
2.50
0.4
2.50
Start-up current
IA
6.00 A
43.30 A
3.50 A
25.00 A
2.90 A
20.80 A
cos phi A 0.75
0.90
0.75
0.90
0.75
0.90
Rated current IN 4.30 A
10.4 A
2.20 A
5.30 A
2.10 A
5.00 A
cos phi N 0.59
0.79
0.59
0.79
0.59
0.79
GM 8 800.16-1, 1000.12-1,
1250.10-1, 1600.8-1, 1600.8-
2,
2000.6-2, 2500.5-2 and
3200.4-2
Operating
voltage
208 –
230 V
360 –
400 V
440 –
480 V
Mains frequency 60 Hz 60 Hz 60 Hz
Duty cycle 40 % 40 % 40 %
Switching rate 240 c/h 240 c/h 240 c/h
Rated power 0.48 kW
3.00 kW
0.48 kW
3.00 kW
0.48 kW
3.00 kW
Start-up current
IA
6.00 A
43.30 A
3.50 A
25.00 A
2.90 A
20.80 A
cos phi A 0.75
0.90
0.75
0.90
0.75
0.90
Rated current IN 4.30 A
10.4 A
2.20 A
5.30 A
2.10 A
5.00 A
cos phi N 0.59
0.79
0.59
0.79
0.59
0.79
GM8 800.20-1, 1000.16-1,
1250.12-1, 1600.10-1, 2000.8-
1
1600.10-2, 2000.8-2, 2500.6-2,
3200.5-2 and 4000.4-2
Operating
voltage
220 –
240 V
380 –
415 V
460 –
500 V
Mains frequency 50 Hz 50 Hz 50 Hz
Duty cycle 40 % 40 % 40 %
Switching rate 240 c/h 240 c/h 240 c/h
Rated power 0.5
3.00
0.5
3.00
0.5
3.00
Start-up current
IA
6.00 A
43.30 A
3.50 A
25.00 A
2.90 A
20.80 A
cos phi A 0.75
0.90
0.75
0.90
0.75
0.90
Rated current IN 4.30 A
10.4 A
2.50 A
6.00 A
2.10 A
5.00 A
cos phi N 0.65
0.85
0.65
0.85
0.65
0.85
GM 8 800.20-1, 1000.16-1,
1250.12-1, 1600.10-1, 2000.8-
1
1600.10-2, 2000.8-2, 2500.6-2,
3200.5-2, 4000.4-2
Operating
voltage
208 –
230 V
360 –
400 V
440 –
480 V
Mains frequency 60 Hz 60 Hz 60 Hz
Duty cycle 40 % 40 % 40 %
Switching rate 240 c/h 240 c/h 240 c/h
Rated power 0.6 kW
3.60 kW
0.6 kW
3.60 kW
0.6 kW
3.60 kW
Start-up current
IA
6.00 A
43.30 A
3.50 A
25.00 A
2.90 A
20.80 A
cos phi A 0.75
0.90
0.75
0.90
0.75
0.90
Rated current IN 4.30 A
10.4 A
2.50 A
6.00 A
2.10 A
5.00 A
cos phi N 0.65
0.85
0.65
0.85
0.65
0.85
