Abus ABUCompact GM2 - Technical Data

Ge ne r a l i n for m a tio n | T h e c hai n hoi s t
9
TECHNICAL DATA
Electrical connection
GM2 (all versions)
Operating voltage 220 –
240 V
380 –
415 V
460 –
500 V
Mains frequency 50 Hz 50 Hz 50 Hz
Duty cycle 60 % 60 % 60 %
Switching rate 360 c/h 360 c/h 360 c/h
Rated power 0.09 kW
0.35 kW
0.09 kW
0.35 kW
0.09 kW
0.35 kW
Start-up current IA 1.77 A
5.70 A
1.02 A
3.30 A
0.85 A
2.75 A
cos phi A 0.85
0.93
0.85
0.93
0.85
0.93
Rated current IN 1.35 A
1.90 A
0.80 A
1.14 A
0.65 A
0.92 A
cos phi N 0.56
0.71
0.56
0.71
0.56
0.71
GM 2 (all versions)
Operating voltage 208 –
230 V
360 –
400 V
440 –
480 V
Mains frequency 60 Hz 60 Hz 60 Hz
Duty cycle 60 % 60 % 60 %
Switching rate 360 c/h 360 c/h 360 c/h
Rated power 0.11 kW
0.42 kW
0.11 kW
0.42 kW
0.11 kW
0.42 kW
Start-up current IA 1.77 A
5.70 A
1.02 A
3.30 A
0.85 A
2.75 A
cos phi A 0.85
0.93
0.85
0.93
0.85
0.93
Rated current IN 1.35 A
1.90 A
0.80 A
1.14 A
0.65 A
0.92 A
cos phi N 0.56
0.71
0.56
0.71
0.56
0.71
GM4 (all versions)
Operating voltage 220 –
240 V
380 –
415 V
460 –
500 V
Mains frequency 50 Hz 50 Hz 50 Hz
Duty cycle 60 % 60 % 60 %
Switching rate 360 c/h 360 c/h 360 c/h
Rated power 0.22 kW
0.90 kW
0.22 kW
0.90 kW
0.22 kW
0.90 kW
Start-up current IA 4.80 A
20.0 A
2.80 A
11.5 A
2.30 A
9.60 A
cos phi A 0.85
0.90
0.85
0.90
0.85
0.90
Rated current IN 2.60 A
3.60 A
1.50 A
2.10 A
1.30 A
1.80 A
cos phi N 0.70
0.80
0.70
0.80
0.70
0.80
GM 4 (all versions)
Operating voltage 208 –
230 V
360 –
400 V
440 –
480 V
Mains frequency 60 Hz 60 Hz 60 Hz
Duty cycle 60 % 60 % 60 %
Switching rate 360 c/h 360 c/h 360 c/h
Rated power 0.26 kW
1.10 kW
0.26 kW
1.10 kW
0.26 kW
1.10 kW
Start-up current IA 4.80 A
20.0 A
2.80 A
11.5 A
2.30 A
9.60 A
cos phi A 0.85
0.90
0.85
0.90
0.85
0.90
Rated current IN 2.60 A
3.60 A
1.50 A
2.10 A
1.30 A
1.80 A
cos phi N 0.70
0.80
0.70
0.80
0.70
0.80
