Accu-Chek Aviva User Manual

11
Chapter 1: Understanding Your New System
The ACCU-CHEK Aviva Meter
Infrared (IR) Window –
Transfers data from the
meter to a computer or
PDA.
Display –
Shows results,
messages, and results
stored in memory.
Right and Left Arrow
Buttons –
Press to enter memory,
adjust settings, and scroll
through results.
Test Strip Slot –
Insert test strip here.
Power/Set Button –
Turns the meter on
or o and sets
options.
Battery Door –
Flip open the battery
door by pushing the
tab in the direction
of the arrow.
Code Key Slot –
Insert code key
into this opening.
Battery –
Insert with
(+) symbol
facing up.
Code Key
(for example)

Accu-Chek Aviva Specifications

General

Sample Size	0.6 µL
Test Time	5 seconds
Coding	No coding required
Battery Life	Approximately 1000 tests
Memory	500 test results
Battery Type	1 x 3V lithium (CR2032)
Operating Humidity	10% to 90% RH
Meter Weight	59 g
Measuring Range	10 mg/dL to 600 mg/dL
Automatic Shut Off	After 90 seconds of inactivity
